PRODUCTION

VEHICLE WASHING COMPLEX

OF EXTERNAL CLEANING (WASHING, RINSING, DRYING)

FOR AGRICULTURAL MACHINERY

OF PORTAL TYPE

AMK-ShP

AMK-ShP complex is designed for washing agricultural machinery. Main operations are carried out by self propelled gantry due to which high quality of military vehicles washing is provided. The complex is equipped with individual bottom and undercarriage washing module.

For year-round operation the equipment is installed in a heated room, however, for seasonal (summer) operation can be made with special design and installed outdoors.

АМК-СхП

Technical characteristics of

AMK-ShP complex

Technical characteristics

Unit of
measurement

Value

1.

Efficiency

units/day

up to 100

2.

Dimensions:

- length
- width
- height

mm

16000
7000/12000
6000

3.

Installed electrical power

kW

100,00

4.

Water consumption for technical needs

m3/day

12,00

5.

Coolant consumption

GCal/day

1,50

6.

Compressed air consumption

m3/day

0,85

7.

Maintenance manpower

person/shift

2

If you have questions about our washing complexes, please contact us, our coordinates are listedon the contact page, andalsoviathe order form.
